| Type of Product | Relay |
| Model No | MT2-C93401 |
| Mass (g) | 156 |
| Monotaro ID | 58259024 |
Type of Product |
Relay |
Model No |
MT2-C93401 |
Mass (g) |
156 |
Monotaro ID |
58259024 |
RoHS Directive |
Correspondence |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Length (mm) |
530 |
Height (mm) |
12 |
Name of Manufacturer/Packer/Importer |
Tyco Electronics Japan G.K. |
Pack of |
25 Pcs |
Width (mm) |
102 |
Specifications |
Coil Voltage = 5 V DC Coil Power = 150mW Coil Resistance = 168 Ω Withstand Voltage Between Coil and Contact = 1.5kV Contact Configuration = DPDT Mounting Type = Board Mount Switching Current = 2A Terminal Type = Through Hole Maximum Switching Voltage AC = 250 V AC maximum Switching voltage DC = 220 V DC Height = 11mm Signal relay MT2 series. Miniature 2-pole signal relay 2 A rated contacts Through-hole mounting Non-polar coil Bifurcated contacts Dimensions: H 11 mm x W 20 mm x D 10 mm Operating temperature range: -55 to +85℃ |
