Hikoki Resistance Meter -10.0 to 99.9℃, Basic accuracy: ±0.5 (combined accuracy with temperature sensor, RM3545-01

Name: Hikoki Resistance Meter -10.0 to 99.9℃, Basic accuracy: ±0.5 (combined accuracy with temperature sensor, RM3545-01
Brand: HiKOKI
SKU: IND.GEN.646077087
Price: 419348 INR
Availability: InStock

Visit the HiKOKI Store

EMI starts at ₹37259/month. No Cost EMI available.

Available offers

Get Flat 10% off on your First Orders above ₹3,000

View

Get Flat 10% off on your First Order above ₹3,000

View

Get Flat 10% off on your First Order above ₹3,000

View

Get Flat 3% off on First Order above ₹3,000

View

Features

Model No	RM3545-01
Type of Product	Resistance Meter
Function	Temperature correction, temperature conversion, offset voltage correction (OVC), comparator (ABS/REF%), BIN, key lock (OFF/menu lock/all lock), display digit selection function (7 digits/6 digits/5 digits)・Power frequency setting (AUTO/50Hz/60Hz) ・Scaling ・Judgment sound setting ・Auto hold ・Average ・Statistical calculation ・Panel save/load ・D/A output
Monotaro ID	44793649

More HiKOKI General Purpose Resistors products More General Purpose Resistors products

100% Original Products

Secure Payments

100% Buyer Protection

Top Brands

specifications

Model No	RM3545-01
Type of Product	Resistance Meter
Function	Temperature correction, temperature conversion, offset voltage correction (OVC), comparator (ABS/REF%), BIN, key lock (OFF/menu lock/all lock), display digit selection function (7 digits/6 digits/5 digits)・Power frequency setting (AUTO/50Hz/60Hz) ・Scaling ・Judgment sound setting ・Auto hold ・Average ・Statistical calculation ・Panel save/load ・D/A output
Monotaro ID	44793649
Country of Origin	Japan
Import Country	Direct Import from Japan
Name of Manufacturer/Packer/Importer	HIOKI E.E. CORPORATION
RoHS Directive	Correspondence
Power Supply	AC100 V to 240 V, 50Hz/60Hz, Rated power: 40 VA max.
Mass (Kg)	[RM3545, RM3545-01] 2.5, [RM3545-02] 3.2
Included Components	Power cord x 1, Clip-type lead L2101 x 1, Temperature sensor Z2001 x 1, EXTI/O male connector x 1, USB cable (AB type) x 1, Spare fuse x 1
Temperature Measurement Range	-10.0 to 99.9℃, Basic accuracy: ±0.5 (combined accuracy with temperature sensor Z2001), -99.9 to 999.9℃ (analog input)
Effective maximum display value	10mΩ (maximum display 12mΩ, resolution 10nΩ) to 1000MΩ range (maximum display 1200.0MΩ, resolution 100kΩ), 12 switching [when LPON] 1000mΩ (maximum display 12mΩ, resolution 10μΩ) to 1000Ω range (maximum display 12Ω, resolution 10mΩ), 4 switching basic accuracy: ±0.006%rdg.±0.001%fs
Measuring Current	DC 1 A to 100 nA, [When LP ON] 1 mA to 5 μA
Dimension (WxDxH)	215x80x306.5 mm
Open Terminal Voltage	DC 20V max. (10 kΩ range to )・5.5 V max. ( to 1000Ω range) [When LP ON] DC 20 mV max.
Communication Interface	Select one from GP-IB (RM3545-01 only)/ RS-232C/ PRINTER (RS-232C)/USB, Remote function/Communication monitor function/Data output function/Memory (50 pieces)
