| Model No | ERJU06F1202V |
| Type of Product | SMD Resistor |
| Series | ERJ |
| Tolerance | ±1% |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Model No |
ERJU06F1202V |
Type of Product |
SMD Resistor |
Series |
ERJ |
Tolerance |
±1% |
Temperature coefficient |
±100 ppm/℃ |
Monotaro ID |
65238357 |
Technology |
Thick Film |
Package / Case |
0805 (2012M) |
Maximum Operating Temperature |
155℃ |
Country of Origin |
Japan |
Minimum Operating Temperature |
-55℃ |
Import Country |
Direct Import from Japan |
Pack of |
100 Pcs |
Name of Manufacturer/Packer/Importer |
Panasonic Corporation |
Resistance (kΩ) |
12 |
Specifications |
0805 Type Anti-Sulfur Resistors, ERJ-U Series. Panasonic's ERJ U series is a surface-mount, thick-film chip resistor suitable for both reflow and flow soldering. Features and Benefits: The ERJ-U series uses an Ag-Pd-based internal electrode for high resistance to sulfuration. All case sizes from 0201 to 2512 are available. Single chip resistors and arrays are also available in 0402 and 0603 case sizes, as well as high-density, space-saving 2, 4, and 8 resistor configurations. Easy installation and a range of power ratings offer cost savings, making them easy to incorporate into new designs. An optional wide terminal type (case size 2010) improves solder joint reliability and power handling characteristics. High reliability achieved through metal glaze thick-film resistive element and triple-layer electrodes. Suitable for automotive, industrial, factory automation, and power supply applications exposed to high-sulfur environments. |
RoHS Directive |
Correspondence |
Rated power (W) |
0.125 |
