| Model No | ERJP06F4020V |
| Type of Product | Film Resistor |
| Series | ERJP06 |
| Tolerance | ±1% |
Model No |
ERJP06F4020V |
Type of Product |
Film Resistor |
Series |
ERJP06 |
Tolerance |
±1% |
Temperature coefficient |
±100℃ |
Monotaro ID |
48164665 |
Resistance (Ω) |
402 |
Technology |
Thick Film |
Package / Case |
805 |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Pack of |
100 Pcs |
Name of Manufacturer/Packer/Importer |
Panasonic Corporation |
Specifications |
IEC60115-8, JISC5201-8, EIAKRC-2134.0805 type anti-surge resistor, ERJP06 series -1% (10Ω to 9.31kΩ). Panasonic ERJP06 anti-surge thick film chip resistor has metal glaze thick film resistor on 3 layers of electrodes It consists of a device and has a protective coating. This structure realizes high reliability and enables reflow and flow soldering. .Surge characteristics superior to AEC-Q200 qualified 0.50W high rated power surge resistant standard membrane resistor.Applications.These chip resistors are AEC-Q200 qualified and can be used for automotive applications. |
Rated power (W) |
0.5 |
Case Type |
mold |
Height (mm) |
0.6 |
Operating Temperature (c) |
-55-155 |
Length (mm) |
2 |
