| Model No | ERJU08F2702V |
| Type of Product | Film Resistor |
| Series | ERJU |
| Tolerance | ±1% |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Model No |
ERJU08F2702V |
Type of Product |
Film Resistor |
Series |
ERJU |
Tolerance |
±1% |
Temperature coefficient |
±100℃ |
Monotaro ID |
47827789 |
Technology |
Thick Film |
Package / Case |
1206 |
Country of Origin |
Japan |
Termination Style |
Solder |
Import Country |
Direct Import from Japan |
Pack of |
100 Pcs |
Name of Manufacturer/Packer/Importer |
Panasonic Corporation |
Resistance (kΩ) |
27 |
Specifications |
1206 Size Sulphide Resistant Resistor, Erj-U Series. The Panasonic Erj-U Sulphide Resistant Resistor Demonstrates High Resistance To Sulfuration By Using Ag-Pd Based Internal Electrodes. These Chip Resistors Are Composed Of Metal Glaze Thick Film Resistor Elements And Three-Layer Electrodes, And Boast High Reliability. Erj-U Resistors Are Ideal For Applications Exposed To High Sulfur Environments. Suitable Applications Include Ecus, Navigation Systems, Dc-Dc Power Supplies, Memory Modules (Ssd, Ddr), Pcs And Servers. This Series Is Aec-Q200 Qualified And Can Be Used In Automotive Applications. .Features And Benefits.Single Chip Resistors Are Available In All Chip Sizes From 0201 To 2512. Reduced Cost, Easy Installation, Space-Saving Design Wide Case Size And Excellent Power Dissipation Excellent Heat Dissipation 0402 And 0603 Case Sizes, 2/4 Wide Resistor Type (Case Size 2010) With Excellent Solder Joint Reliability And Power Handling Characteristics Also Available |
Rated power (W) |
0.25 |
Case Type |
Metal |
Height (mm) |
0.6 |
Operating Temperature (c) |
-55-155 |
Length (mm) |
3.2 |
