| Model No | ERJU06F7502V |
| Type of Product | Film Resistor |
| Series | ERJ |
| Tolerance | ±1% |
Model No |
ERJU06F7502V |
Type of Product |
Film Resistor |
Series |
ERJ |
Tolerance |
±1% |
Temperature coefficient |
±100℃ |
Monotaro ID |
48238628 |
Technology |
Thick Film |
Package / Case |
805 |
Country of Origin |
Japan |
Termination Style |
Solder |
Import Country |
Direct Import from Japan |
Pack of |
100 Pcs |
Name of Manufacturer/Packer/Importer |
Panasonic Corporation |
Resistance (kΩ) |
75 |
Specifications |
0805 type sulfur resistant resistor, ERJ-U series. Panasonic's ERJU series is a surface mount film thickness chip resistor, suitable for both reflow and flow soldering. .Features and advantages The ERJ-U series uses Ag-Pd-based internal electrodes to exhibit high resistance to sulfuration. All case sizes from 0201 to 2512 are available. For single chip resistors and arrays, 0402 and 0603 case sizes and high-density and space-saving 2/4/8 resistor configurations are available. Optional wide terminal type (case size 2010) for easy installation and cost savings with various power ratings for improved solder joint reliability and power handling characteristics. High reliability achieved by metal glaze thick film resistance element and three-layer electrode Suitable for automotive, industrial, factory automation, power supply, etc. exposed to high sulfur environment |
Rated power (W) |
0.125 |
Case Type |
mold |
Height (mm) |
0.6 |
Operating Temperature (c) |
-55-155 |
Length (mm) |
2 |
