| Type of Product | Digimatic Height Gauge |
| Model No | HD-60AX |
| Power Supply | One Button-Type Silver Oxide Battery SR44 (No. 938882) Is Included As Standard (The Button-Type Silver Oxide Battery Included As Standard Is For Monitor Use) |
| Country of Origin | Japan |
Type of Product |
Digimatic Height Gauge |
Model No |
HD-60AX |
Power Supply |
One Button-Type Silver Oxide Battery SR44 (No. 938882) Is Included As Standard (The Button-Type Silver Oxide Battery Included As Standard Is For Monitor Use) |
Country of Origin |
Japan |
Included Components |
Scriber (No.07GZA000), Scriber Clamp Box (05GZA033) |
Battery Life (hours) |
Approximately 3500 in continuous use |
Overall Height (mm) |
802 |
Maximum Response Speed (mm/s) |
500 |
Display Format |
Digital |
Function |
Origin setting function (ABS measurement system), zero setting function (INC measurement system), origin return function, preset function (ABS/INC measurement system), direction switching function, hold function, error warning function, measurement data output function, coarse/fine movement switching, low battery voltage warning, ball diameter correction |
Repeatability (mm) |
0.01 mm |
RoHS Directive |
Correspondence |
Series |
192 |
Monotaro ID |
10174972 |
Product Type |
Body |
Trusco Part No. |
336-1705 |
Minimum Reading (mm) |
0.01/0.005 mm Switchable |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Mitutoyo Corporation |
Mass (Kg) |
8.3000000000000007 |
Product Code |
192-614-10 |
Measuring_Range |
600 mm |
Maximum Permissible Error (μm) |
EMPE：±50 |
Adaptive Accessories |
Connection cable for IT/DP/MUX, etc. 1m (No. 905338) 2m (No. 905409), USB Input Tool Direct 2m USB-ITN-F (No. 06AFM380F), U-WAVE-T dedicated connection cable standard (No. 02AZD790F) for foot switch (No. 02AZE140F), holder arm (No. 953638), clamp (No. 902053) (with Φ6 and Φ8 dovetail grooves) |
Allowable Tolerance |
Maximum: ±0.05mm |
