| Model No | PFXET6700WAD |
| Weight | 2.52 kg |
| Display Color | 16 million colours |
| Touch Panel Type | Single touch analogue resistive |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Model No |
PFXET6700WAD |
Weight |
2.52 kg |
Display Color |
16 million colours |
Touch Panel Type |
Single touch analogue resistive |
Screen Type |
Touch Panel Screen |
Type of Product |
HMI Touch Panel |
Vibration Resistance |
+/- 3.5 mm (f = 5…9 Hz) X, Y, Z directions for 10 cycles (approx. 100 min) conforming to IEC 61131-2, 9.8 m/s² (f = 9…150 Hz) |
Relative Humidity |
10 to 90 % non-condensing |
Operating Altitude |
2000 m |
Processor Name |
ARM Cortex-A8 |
Display Type |
Colour TFT LCD |
Display Size |
15 inch (381 mm) |
Display Resolution |
1366 x 768 pixels FWXGA |
Shock Resistance |
147 m/s² for 11 ms (X, Y, Z directions for 3 times) conforming to IEC 61131-2 |
IP Rating |
IP20 (rear panel) conforming to IEC 61131-2, IP65 (front panel) conforming to IEC 61131-2 |
Power Consumption |
18.5 W |
Memory |
User data memory - 64 MB, Backup memory - 128 kB |
Software |
GP-Pro EX |
Brightness |
16 levels |
Port Ethernet |
10/100BASE |
Local signalling |
Status LED green, steady for offline, Status LED green, steady for operating, Status LED green, flashing for logic stop, Status LED orange, flashing for software starting up, Status LED red, steady for power supply (ON), Status LED, off for power supply (OFF) |
Inrush Current |
30 A |
Certification |
CE, UL, KC, UKCA |
Standard |
IEC 61000-6-4, IEC 61000-6-2, IEC 61131-2, UL 61010-2-201, CSA C22.2 No 61010-1-201 |
Country of Origin |
Japan |
Depth |
50 mm |
Width |
412 mm |
Real Time Clock |
Built-in 0...50 °C, Built-in 10...90 % RH |
Name of Manufacturer/Packer/Importer |
LADDER LOGIX |
Integrated Connection Type |
1 COM1 serial link - 1 SUB-D 9-pin male - RS232C (rate: 2400...115200 bps)bottom, 1 COM2 serial link - 1 SUB-D 9-pin male - RS422/RS485 (rate: 2400...115200 bps)bottom, COM2 serial link (rate: 2400...187500 bps)bottom, 1 Ethernetbottom, 1 USB 2.0 type Aback, 1 USB 2.0 type micro Bback |
Supply |
External supply |
Cut-Out Size (Mm) |
394 x 250 mm panel cut dimension |
Height |
268 mm |
Electromagnetic Compatibility |
Electrical fast transient/burst immunity test - test level: 2 kV (power ports) conforming to IEC 61000-4-4, Electrical fast transient/burst immunity test - test level: 1 kV (signal ports), Electrostatic discharge immunity test - test level: 6 kV (contact discharge) conforming to IEC 61000-4-2 level 3, Electrostatic discharge immunity test - test level: 8 kV (air discharge) |
device memory |
256 MB |
Immunity to Microbreaks |
5 ms |
rated supply voltage |
24 V DC +/- 20 % |
Ambient Air Temperature for Storage |
-20 to 60 °C |
Fixing Mode |
By 6 screws, mounting on 1.6...5 mm thick panel |
Ambient Air Temperature for Operation |
0 to 50 °C |
Enclosure Material |
PC |
