| Type of Product | Hybrid Solar Inverter |
| Phase | 3 |
| Frequency | 50 Hz |
| Model No | EHY-10KW-3P |
Type of Product |
Hybrid Solar Inverter |
Phase |
3 |
Frequency |
50 Hz |
Model No |
EHY-10KW-3P |
Dimension |
386 × 660 × 250 mm |
Country of Origin |
India |
Warranty Duration |
10 Years |
Name of Manufacturer/Packer/Importer |
EAPL |
Maximum Input Voltage |
800 VDC |
Nominal Output Voltage |
400 V |
Rated Output Power |
10 kW |
Surge Protection |
Type II |
Short Circuit Current |
34+17 Amp (Max) |
Interface |
RS232, RS485, CAN |
No. of MPP Trackers |
2 |
Start-up DC input Voltage |
160 V |
Maximum Input Current |
DC 26+13 Amp |
Ingress Protection |
IP65 |
Rated Output Power (VA) |
11000 VA |
MPPT Operating Range (V) |
200-650 V |
Maximum Input Power |
1300 W (DC) |
