Hafele 3D Concealed Hinge TE540 Series 180 ° Opening Angle DIN Left/Right Mounting Black Matt Finish Suitable for Flush Doors Up to 120 Kg, 924.17.237

Share

Ships within 10 days

Hafele 3D Concealed Hinge TE540 Series 180 ° Opening Angle DIN Left/Right Mounting Black Matt Finish Suitable for Flush Doors Up to 120 Kg, 924.17.237

hafele-3d-concealed-hinge-te540-series-180-opening-angle-din-leftright-mounting-black-matt-finish-suitable-for-flush-doors-up-to-120-kg-92417237

hafele-3d-concealed-hinge-te540-series-180-opening-angle-din-leftright-mounting-black-matt-finish-suitable-for-flush-doors-up-to-120-kg-92417237

hafele-3d-concealed-hinge-te540-series-180-opening-angle-din-leftright-mounting-black-matt-finish-suitable-for-flush-doors-up-to-120-kg-92417237

hafele-3d-concealed-hinge-te540-series-180-opening-angle-din-leftright-mounting-black-matt-finish-suitable-for-flush-doors-up-to-120-kg-92417237

hafele-3d-concealed-hinge-te540-series-180-opening-angle-din-leftright-mounting-black-matt-finish-suitable-for-flush-doors-up-to-120-kg-92417237

hafele-3d-concealed-hinge-te540-series-180-opening-angle-din-leftright-mounting-black-matt-finish-suitable-for-flush-doors-up-to-120-kg-92417237

hafele-3d-concealed-hinge-te540-series-180-opening-angle-din-leftright-mounting-black-matt-finish-suitable-for-flush-doors-up-to-120-kg-92417237

hafele-3d-concealed-hinge-te540-series-180-opening-angle-din-leftright-mounting-black-matt-finish-suitable-for-flush-doors-up-to-120-kg-92417237

Hafele 3D Concealed Hinge TE540 Series 180 ° Opening Angle DIN Left/Right Mounting Black Matt Finish Suitable for Flush Doors Up to 120 Kg, 924.17.237

Visit the Hafele Store

EMI starts at ₹1813/month. No Cost EMI available.

Available offers

Get Flat 10% off on your First Orders above ₹3,000

View

Get Flat 10% off on your First Order above ₹3,000

View

Get Flat 10% off on your First Order above ₹3,000

View

Get Flat 3% off on First Order above ₹3,000

View

Features

Type of Product	3D Concealed Hinge
Suitable For	Flush Doors Up to 120 Kg for 2 Hinges (40 mm Minimum Door Thickness)
Series	TE540
Country of Origin	Germany

More Hafele Hydraulic Hinge products More Hydraulic Hinge products

100% Original Products

Secure Payments

100% Buyer Protection

Top Brands

specifications

description

Type of Product	3D Concealed Hinge
Suitable For	Flush Doors Up to 120 Kg for 2 Hinges (40 mm Minimum Door Thickness)
Series	TE540
Country of Origin	Germany
Name of Manufacturer/Packer/Importer	ECO PIPE COMPANY
Opening Angle	180 °
Frame Type	Steel Frame, Aluminium Frame, Wooden/Lining Frame
Shape	Rounded Flange
Height	200 mm
Item Code	924.17.237
Finish Color	Black Matt Finish
Standard	EN 1935:2002
Mounting	DIN Left/Right
Width	32 mm
