| Type of Product | Incremental Encoder |
| Shaft Diameter | 38 mm |
| Current Rating | 110 mA |
| IP Rating | IP65 |
Type of Product |
Incremental Encoder |
Shaft Diameter |
38 mm |
Current Rating |
110 mA |
IP Rating |
IP65 |
Pulses Per Revolution |
1024 |
Overall Depth |
50 mm |
Overall Height |
100 mm |
Maximum Operating Temperature |
+80°C |
Country of Origin |
Germany |
Supply Voltage |
10-30 V DC |
Overall Width |
129.8 mm |
Connection Type |
Cable |
Mounting Type |
Hollow Shaft Flange |
Minimum Operating Temperature |
-40°C |
Shaft Type |
Hollow |
Series |
A02H |
Name of Manufacturer/Packer/Importer |
KUBLER |
Output Signal Type |
Push Pull |
Product Code |
1811067 |
Manufacturer Part Number |
8.A02H.5231.1024 |
Encoder Technology |
Incremental |
Switching Frequency |
180 kHz |
Interface |
Push-Pull |
