| Type of Product | TVS Diode Array |
| Dimension | 2.2 x 1.35 x 1 mm |
| Height | 1 mm |
| Width | 1.35 mm |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
TVS Diode Array |
Dimension |
2.2 x 1.35 x 1 mm |
Height |
1 mm |
Width |
1.35 mm |
Country of Origin |
United Kingdom |
Pack of |
100 Pcs |
Mounting Type |
Surface Mount |
Maximum Operating Temperature |
+150°C |
Minimum Operating Temperature |
-55°C |
Length |
2.2 mm |
Name of Manufacturer/Packer/Importer |
Diodes Zetex Semiconductors Limited |
Package Type |
SOT-363 (SC-88) |
Pin Count |
6 |
Manufacturer Part Number |
DT1446-04S-7 |
Capacitance |
0.65pF |
Test Current |
1 mA |
Diode Configuration |
Array |
Number of Elements Per Chip |
10 |
Direction Type |
Uni-Directional |
Minimum Breakdown Voltage |
6V |
Maximum Clamping Voltage |
8.5V |
Peak Pulse Power Dissipation |
0.2W |
Maximum Reverse Leakage Current |
5 µA |
ESD Protection |
Yes |
Maximum Reverse Stand-off Voltage |
5V |
Maximum Peak Pulse Current |
4.7A |
Working Voltage |
6V |
