| Type of Product | TVS Diode |
| Dimension | 0.64 x 0.34 x 0.32 mm |
| Height | 0.32 mm |
| Width | 0.34 mm |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
TVS Diode |
Dimension |
0.64 x 0.34 x 0.32 mm |
Height |
0.32 mm |
Width |
0.34 mm |
Country of Origin |
China |
Pack of |
10000 Pcs |
Mounting Type |
Surface Mount |
Maximum Operating Temperature |
+150°C |
Minimum Operating Temperature |
-65°C |
Length |
0.64 mm |
Name of Manufacturer/Packer/Importer |
Diodes Zetex Semiconductors Limited |
Package Type |
X3-DFN0603 |
Pin Count |
2 |
Manufacturer Part Number |
D15V0M1U2LP3-7 |
Capacitance |
19pF |
Diode Configuration |
Single |
Number of Elements Per Chip |
1 |
Direction Type |
Uni-Directional |
Minimum Breakdown Voltage |
15.5V |
Maximum Clamping Voltage |
24V |
Peak Pulse Power Dissipation |
75W |
Maximum Reverse Leakage Current |
1 µA |
ESD Protection |
Yes |
Maximum Reverse Stand-off Voltage |
15V |
Maximum Peak Pulse Current |
3A |
