| Type of Product | NPN Darlington Transistor |
| Dimension | 3 x 1.4 x 1.1 mm |
| Height | 1.1 mm |
| Width | 1.4 mm |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
NPN Darlington Transistor |
Dimension |
3 x 1.4 x 1.1 mm |
Height |
1.1 mm |
Width |
1.4 mm |
Country of Origin |
China |
Pack of |
3000 Pcs |
Mounting Type |
Surface Mount |
Maximum Operating Temperature |
+150°C |
Minimum Operating Temperature |
-55°C |
Length |
3 mm |
Name of Manufacturer/Packer/Importer |
Diodes Zetex Semiconductors Limited |
Package Type |
SOT-23 |
Pin Count |
3 |
Manufacturer Part Number |
FMMT614TA |
DC Current Gain |
5000 (Min.) |
Number of Elements Per Chip |
1 |
transistor Type |
NPN |
Maximum Collector Emitter Voltage |
100 V |
Transistor Configuration |
Single |
Maximum Emitter Base Voltage |
10 V |
Maximum Collector Base Voltage |
120 V |
Maximum Base Emitter Saturation Voltage |
1.9 V |
Maximum Collector Emitter Saturation Voltage |
1 V |
Maximum Continuous Collector Current |
500 mA |
Maximum Collector Cut-off Current |
0.00001 mA |
