| Type of Product | Voltage Regulator |
| Dimension | 3.02 x 1.7 x 1.3 mm |
| Height | 1.3 mm |
| Width | 1.7 mm |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Voltage Regulator |
Dimension |
3.02 x 1.7 x 1.3 mm |
Height |
1.3 mm |
Width |
1.7 mm |
Country of Origin |
United Kingdom |
Line Regulation |
15 mV |
Output Voltage |
3.3 V |
Load Regulation |
15 mV |
Pack of |
100 Pcs |
Mounting Type |
Surface Mount |
No. Of Output |
1 |
Maximum Operating Temperature |
+85°C |
Minimum Operating Temperature |
-40°C |
Length |
3.02 mm |
Name of Manufacturer/Packer/Importer |
Diodes Zetex Semiconductors Limited |
Package Type |
SOT-23 |
Pin Count |
5 |
Maximum Input Voltage |
6 V |
Output Type |
Fixed |
Accuracy |
±2% |
Manufacturer Part Number |
AP2125K-3.3TRG1 |
Polarity |
Positive |
Quiescent current |
90 µA |
Regulator Type |
Low Dropout Voltage |
