| Type of Product | Voltage Regulator |
| Dimension | 4.6 x 2.6 x 1.6 mm |
| Height | 1.6 mm |
| Width | 2.6 mm |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Voltage Regulator |
Dimension |
4.6 x 2.6 x 1.6 mm |
Height |
1.6 mm |
Width |
2.6 mm |
Country of Origin |
United Kingdom |
Line Regulation |
750 mV |
Output Voltage |
13.2 V |
Load Regulation |
-750 mV |
Pack of |
20 Pcs |
Mounting Type |
Surface Mount |
No. Of Output |
1 |
Maximum Operating Temperature |
+125°C |
Minimum Operating Temperature |
-40°C |
Length |
4.6 mm |
Power Rating |
1.7 W |
Name of Manufacturer/Packer/Importer |
Diodes Zetex Semiconductors Limited |
Package Type |
SOT-89 |
Pin Count |
3 |
Minimum Input Voltage |
15 V |
Maximum Input Voltage |
100 V |
Output Type |
Fixed |
Maximum Output Current |
47mA |
Accuracy |
±10% |
Manufacturer Part Number |
ZXTR2012Z-13 |
Polarity |
Positive |
Quiescent current |
900 µA |
Regulator Type |
Linear Voltage |
