| Type of Product | NPN Darlington Transistor |
| Dimension | 6.55 x 3.55 x 1.65 mm |
| Height | 1.65 mm |
| Width | 3.55 mm |
Type of Product |
NPN Darlington Transistor |
Dimension |
6.55 x 3.55 x 1.65 mm |
Height |
1.65 mm |
Width |
3.55 mm |
Country of Origin |
United Kingdom |
Pack of |
10 Pcs |
Mounting Type |
Surface Mount |
Maximum Operating Temperature |
+150°C |
Minimum Operating Temperature |
-55°C |
Length |
6.55 mm |
Name of Manufacturer/Packer/Importer |
Diodes Zetex Semiconductors Limited |
Package Type |
SOT-223 |
Pin Count |
3+Tab |
Manufacturer Part Number |
FZT696BTA |
DC Current Gain |
150 (Min.) |
Number of Elements Per Chip |
1 |
transistor Type |
NPN |
Maximum Collector Emitter Voltage |
180 V |
Maximum Power Dissipation |
2 W |
Transistor Configuration |
Single |
Maximum Emitter Base Voltage |
5 V |
Maximum Collector Base Voltage |
180 V |
Maximum Base Emitter Saturation Voltage |
0.9 V |
Maximum Collector Emitter Saturation Voltage |
0.25 V |
Maximum Continuous Collector Current |
500 mA |
Maximum Collector Cut-off Current |
0.1 µA |
