| Type of Product | PNP Darlington Transistor |
| Dimension | 6.7 x 3.7 x 1.65 mm |
| Height | 1.65 mm |
| Width | 3.7 mm |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
PNP Darlington Transistor |
Dimension |
6.7 x 3.7 x 1.65 mm |
Height |
1.65 mm |
Width |
3.7 mm |
Country of Origin |
Germany |
Pack of |
4000 Pcs |
Mounting Type |
Surface Mount |
Maximum Operating Temperature |
+150°C |
Minimum Operating Temperature |
-55°C |
Length |
6.7 mm |
Name of Manufacturer/Packer/Importer |
Diodes Zetex Semiconductors Limited |
Package Type |
SOT-223 |
Pin Count |
3+Tab |
Manufacturer Part Number |
FZT705TC |
DC Current Gain |
2000 (Min.) |
Number of Elements Per Chip |
1 |
transistor Type |
PNP |
Maximum Collector Emitter Voltage |
120 V |
Transistor Configuration |
Single |
Maximum Emitter Base Voltage |
10 V |
Maximum Collector Base Voltage |
140 V |
Maximum Base Emitter Saturation Voltage |
1.8 V |
Maximum Collector Emitter Saturation Voltage |
2.5 V |
Maximum Continuous Collector Current |
2 A |
Maximum Collector Cut-off Current |
0.0001 mA |
