| Type of Product | Dual N/P-Channel MOSFET |
| Height | 0.6 mm |
| Width | 1.25 mm |
| Country of Origin | China |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Dual N/P-Channel MOSFET |
Height |
0.6 mm |
Width |
1.25 mm |
Country of Origin |
China |
Pack of |
3000 Pcs |
Mounting Type |
Surface Mount |
Maximum Operating Temperature |
+150°C |
Minimum Operating Temperature |
-55°C |
Length |
1.7 mm |
Name of Manufacturer/Packer/Importer |
Diodes Zetex Semiconductors Limited |
Package Type |
SOT-563 |
Pin Count |
6 |
Manufacturer Part Number |
DMG1029SV-7 |
Continuous Drain Current |
280 mA, 620 mA (Max.) |
Drain Source Voltage |
60 V (Max.) |
Channel Type |
N, P |
Number of Elements Per Chip |
2 |
Channel Mode |
Enhancement |
Transistor Material |
Si |
Maximum Gate Threshold Voltage |
3 V |
Maximum Drain Source Resistance |
1.7 Ω, 6 Ω |
Maximum Gate Source Voltage |
-20 V, +20 V |
Typical Gate Charge @ Vgs |
0.28 nC @ 4.5 V, 0.3 nC @ 4.5 V |
Maximum Power Dissipation |
1 W |
Transistor Configuration |
Isolated |
