| Type of Product | Bridge Rectifier |
| Dimension | 4.9 x 4 x 2.7 mm |
| Height | 2.7 mm |
| Width | 4 mm |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Bridge Rectifier |
Dimension |
4.9 x 4 x 2.7 mm |
Height |
2.7 mm |
Width |
4 mm |
Country of Origin |
China |
Pack of |
50 Pcs |
Mounting Type |
Surface Mount |
Maximum Operating Temperature |
+150°C |
Minimum Operating Temperature |
-55°C |
Length |
4.9 mm |
Name of Manufacturer/Packer/Importer |
Diodes Zetex Semiconductors Limited |
Package Type |
MiniDIP SMD |
Pin Count |
4 |
Manufacturer Part Number |
HD04-T |
Bridge Type |
Single Phase |
Configuration |
Single |
Peak Reverse Repetitive Voltage |
400 V |
Peak Non-Repetitive Forward Surge Current |
30A |
Peak Average Forward Current |
800mA |
Peak Reverse Current |
500 mA |
Peak Forward Voltage |
1 V |
