| Type of Product | N-Channel MOSFET |
| Height | 0.58 mm |
| Width | 2.05 mm |
| Country of Origin | China |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
N-Channel MOSFET |
Height |
0.58 mm |
Width |
2.05 mm |
Country of Origin |
China |
Pack of |
3000 Pcs |
Mounting Type |
Surface Mount |
Maximum Operating Temperature |
+150°C |
Minimum Operating Temperature |
-55°C |
Length |
2.05 mm |
Series |
DMN3042LFDF |
Name of Manufacturer/Packer/Importer |
Diodes Zetex Semiconductors Limited |
Package Type |
U-DFN2020 |
Pin Count |
6 |
Manufacturer Part Number |
DMN3042LFDF-7 |
Continuous Drain Current |
7 A (Max.) |
Drain Source Voltage |
30 V (Max.) |
Channel Type |
N |
Number of Elements Per Chip |
1 |
Channel Mode |
Enhancement |
Maximum Gate Threshold Voltage |
1.4 V |
Maximum Drain Source Resistance |
50 mΩ |
Maximum Gate Source Voltage |
-12 V, +12 V |
Minimum Gate Threshold Voltage |
0.6V |
Typical Gate Charge @ Vgs |
13.3 nC @ 15 V |
Forward Diode Voltage |
1.2V |
Maximum Power Dissipation |
2.1 W |
Transistor Configuration |
Single |
