| Type of Product | Bi-Directional TVS Diode |
| Dimension | 4.57 x 3.94 x 2.42 mm |
| Height | 2.42 mm |
| Width | 3.94 mm |
Type of Product |
Bi-Directional TVS Diode |
Dimension |
4.57 x 3.94 x 2.42 mm |
Height |
2.42 mm |
Width |
3.94 mm |
Country of Origin |
United Kingdom |
Pack of |
25 Pcs |
Mounting Type |
Surface Mount |
Maximum Operating Temperature |
+150°C |
Minimum Operating Temperature |
-55°C |
Length |
4.57 mm |
Name of Manufacturer/Packer/Importer |
Diodes Zetex Semiconductors Limited |
Package Type |
DO-214AA (SMB) |
Pin Count |
2 |
Manufacturer Part Number |
SMBJ24CA-13-F |
Test Current |
1 mA |
Diode Configuration |
Single |
Number of Elements Per Chip |
1 |
Direction Type |
Bi-Directional |
Minimum Breakdown Voltage |
26.7V |
Maximum Clamping Voltage |
38.9V |
Peak Pulse Power Dissipation |
600W |
Maximum Reverse Leakage Current |
5 µA |
Maximum Reverse Stand-off Voltage |
24V |
Maximum Peak Pulse Current |
15.4A |
