| Type of Product | Op Amp |
| Dimension | 3.1 x 3.1 x 0.95 mm |
| Height | 0.95 mm |
| Width | 3.1 mm |
Type of Product |
Op Amp |
Dimension |
3.1 x 3.1 x 0.95 mm |
Height |
0.95 mm |
Width |
3.1 mm |
Country of Origin |
United Kingdom |
Output Current |
50 (Sink) \xce\xbcA, -60 (Source) mA |
Pack of |
50 Pcs |
Mounting Type |
Surface Mount |
Maximum Operating Temperature |
+125°C |
Minimum Operating Temperature |
-40°C |
Length |
3.1 mm |
Name of Manufacturer/Packer/Importer |
Diodes Zetex Semiconductors Limited |
Package Type |
MSOP |
Pin Count |
8 |
Minimum Input Voltage |
±1.5 (Dual) V, 3 (Single) V |
Maximum Input Voltage |
±18 (Dual) V, 36 (Single) V |
Power Supply Type |
Dual, Single |
Number of Channels Per Chip |
2 |
Voltage Gain |
100 dB (Typical) |
Manufacturer Part Number |
LM2904M8-13 |
Slew Rate |
0.3V/µs (Typical) |
Amplifier Type |
Low Power |
Maximum Operating Frequency |
20 kHz |
Input Voltage Range |
±1.5 → ±18 V, 3 → 36 V |
Offset Voltage |
10mV |
Input Offset Current |
150nA |
Typical Gain Bandwidth Product |
700kHz |
Rail to Rail |
No |
Typical Input Voltage Noise Density |
40nV/√Hz |
