| Type of Product | N-Channel MOSFET |
| Height | 0.48 mm |
| Width | 0.675 mm |
| Country of Origin | China |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
N-Channel MOSFET |
Height |
0.48 mm |
Width |
0.675 mm |
Country of Origin |
China |
Pack of |
10000 Pcs |
Mounting Type |
Surface Mount |
Maximum Operating Temperature |
+150°C |
Minimum Operating Temperature |
-55°C |
Length |
1.08 mm |
Name of Manufacturer/Packer/Importer |
Diodes Zetex Semiconductors Limited |
Package Type |
X1-DFN1006 |
Pin Count |
3 |
Manufacturer Part Number |
DMN1150UFB-7B |
Continuous Drain Current |
1.4 A (Max.) |
Drain Source Voltage |
12 V (Max.) |
Channel Type |
N |
Number of Elements Per Chip |
1 |
Channel Mode |
Enhancement |
Transistor Material |
Si |
Maximum Gate Threshold Voltage |
1 V |
Maximum Drain Source Resistance |
210 mΩ |
Maximum Gate Source Voltage |
-6 V, +6 V |
Typical Gate Charge @ Vgs |
1.5 nC @ 4.5 V |
Maximum Power Dissipation |
500 mW |
Transistor Configuration |
Single |
