| Type of Product | N-Channel MOSFET |
| Height | 2.39 mm |
| Width | 6.22 mm |
| Country of Origin | China |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
N-Channel MOSFET |
Height |
2.39 mm |
Width |
6.22 mm |
Country of Origin |
China |
Pack of |
2500 Pcs |
Mounting Type |
Surface Mount |
Maximum Operating Temperature |
+150°C |
Minimum Operating Temperature |
-55°C |
Length |
6.73 mm |
Name of Manufacturer/Packer/Importer |
Diodes Zetex Semiconductors Limited |
Package Type |
DPAK (TO-252) |
Pin Count |
3 |
Manufacturer Part Number |
DMN4036LK3-13 |
Continuous Drain Current |
12.2 A (Max.) |
Drain Source Voltage |
40 V (Max.) |
Channel Type |
N |
Number of Elements Per Chip |
1 |
Channel Mode |
Enhancement |
Transistor Material |
Si |
Maximum Gate Threshold Voltage |
3 V |
Maximum Drain Source Resistance |
61 mΩ |
Maximum Gate Source Voltage |
-20 V, +20 V |
Typical Gate Charge @ Vgs |
9.2 nC @ 10 V |
Maximum Power Dissipation |
8.49 W |
Transistor Configuration |
Single |
