| Type of Product | P-Channel MOSFET |
| Height | 0.8 mm |
| Width | 0.85 mm |
| Country of Origin | China |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
P-Channel MOSFET |
Height |
0.8 mm |
Width |
0.85 mm |
Country of Origin |
China |
Pack of |
3000 Pcs |
Mounting Type |
Surface Mount |
Maximum Operating Temperature |
+150°C |
Minimum Operating Temperature |
-55°C |
Length |
1.7 mm |
Name of Manufacturer/Packer/Importer |
Diodes Zetex Semiconductors Limited |
Package Type |
SOT-523 (SC-89) |
Pin Count |
3 |
Manufacturer Part Number |
DMG1013T-7 |
Continuous Drain Current |
460 mA (Max.) |
Drain Source Voltage |
20 V (Max.) |
Channel Type |
P |
Number of Elements Per Chip |
1 |
Channel Mode |
Enhancement |
Transistor Material |
Si |
Maximum Gate Threshold Voltage |
1 V |
Maximum Drain Source Resistance |
1.3 Ω |
Maximum Gate Source Voltage |
-6 V, +6 V |
Typical Gate Charge @ Vgs |
0.58 nC @ 4.5 V |
Maximum Power Dissipation |
270 mW |
Transistor Configuration |
Single |
