| Type of Product | N-Channel MOSFET |
| Height | 0.8 mm |
| Width | 3.35 mm |
| Country of Origin | China |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
N-Channel MOSFET |
Height |
0.8 mm |
Width |
3.35 mm |
Country of Origin |
China |
Pack of |
2000 Pcs |
Mounting Type |
Surface Mount |
Maximum Operating Temperature |
+150°C |
Minimum Operating Temperature |
-55°C |
Length |
3.35 mm |
Name of Manufacturer/Packer/Importer |
Diodes Zetex Semiconductors Limited |
Package Type |
PowerDI3333-8 |
Pin Count |
8 |
Manufacturer Part Number |
DMN4010LFG-7 |
Continuous Drain Current |
14.2 A (Max.) |
Drain Source Voltage |
40 V (Max.) |
Channel Type |
N |
Number of Elements Per Chip |
1 |
Channel Mode |
Enhancement |
Transistor Material |
Si |
Maximum Gate Threshold Voltage |
3 V |
Maximum Drain Source Resistance |
15 mΩ |
Maximum Gate Source Voltage |
-20 V, +20 V |
Minimum Gate Threshold Voltage |
1V |
Typical Gate Charge @ Vgs |
37 nC @ 10 V |
Forward Diode Voltage |
0.72V |
Maximum Power Dissipation |
2.45 W |
Transistor Configuration |
Single |
