| Type of Product | Bi-Directional TVS Diode |
| Dimension | 1.8 x 1.4 x 1.1 mm |
| Height | 1.1 mm |
| Width | 1.4 mm |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Bi-Directional TVS Diode |
Dimension |
1.8 x 1.4 x 1.1 mm |
Height |
1.1 mm |
Width |
1.4 mm |
Country of Origin |
China |
Pack of |
3000 Pcs |
Mounting Type |
Surface Mount |
Maximum Operating Temperature |
+150°C |
Minimum Operating Temperature |
-65°C |
Length |
1.8 mm |
Name of Manufacturer/Packer/Importer |
Diodes Zetex Semiconductors Limited |
Package Type |
SOD-323 |
Pin Count |
2 |
Manufacturer Part Number |
DESD5V0S1BA-7 |
Test Current |
1 mA |
Diode Configuration |
Single |
Number of Elements Per Chip |
1 |
Direction Type |
Bi-Directional |
Minimum Breakdown Voltage |
5.5V |
Maximum Clamping Voltage |
14V |
Peak Pulse Power Dissipation |
130W |
Maximum Reverse Leakage Current |
100nA |
ESD Protection |
Yes |
Maximum Reverse Stand-off Voltage |
5V |
Maximum Peak Pulse Current |
12A |
