| Type of Product | P-Channel MOSFET |
| Height | 2.39 mm |
| Width | 6.2 mm |
| Country of Origin | China |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
P-Channel MOSFET |
Height |
2.39 mm |
Width |
6.2 mm |
Country of Origin |
China |
Pack of |
2500 Pcs |
Mounting Type |
Surface Mount |
Maximum Operating Temperature |
+150°C |
Minimum Operating Temperature |
-55°C |
Length |
6.7 mm |
Name of Manufacturer/Packer/Importer |
Diodes Zetex Semiconductors Limited |
Package Type |
DPAK (TO-252) |
Pin Count |
3 |
Manufacturer Part Number |
DMP6180SK3-13 |
Continuous Drain Current |
14 A (Max.) |
Drain Source Voltage |
60 V (Max.) |
Channel Type |
P |
Number of Elements Per Chip |
1 |
Channel Mode |
Enhancement |
Transistor Material |
Si |
Maximum Gate Threshold Voltage |
2.7 V |
Maximum Drain Source Resistance |
140 mΩ |
Maximum Gate Source Voltage |
-20 V, +20 V |
Typical Gate Charge @ Vgs |
17.1 nC @ 10 V |
Maximum Power Dissipation |
1.7 W, 2.7 W, 40 W |
Transistor Configuration |
Single |
