| Type of Product | Schmitt Trigger Inverter IC |
| Dimension | 2.2 x 1.35 x 1 mm |
| Height | 1 mm |
| Width | 1.35 mm |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Schmitt Trigger Inverter IC |
Dimension |
2.2 x 1.35 x 1 mm |
Height |
1 mm |
Width |
1.35 mm |
Country of Origin |
United Kingdom |
Pack of |
200 Pcs |
Mounting Type |
Surface Mount |
Input Type |
Schmitt Trigger |
Maximum Operating Temperature |
+125°C |
Minimum Operating Temperature |
-40°C |
Length |
2.2 mm |
Name of Manufacturer/Packer/Importer |
Diodes Zetex Semiconductors Limited |
Package Type |
SOT-353 |
Pin Count |
5 |
Output Type |
Push-Pull |
Minimum Operating Supply Voltage |
1.65 V |
Maximum Operating Supply Voltage |
5.5 V |
Manufacturer Part Number |
74LVC1G14SE-7 |
Logic Function |
Inverter |
Number of Elements Per Chip |
1 |
Schmitt Trigger Input |
Yes |
Maximum Propagation Delay Time at Maximum CL |
6.5 ns @ 50 pF |
Propagation Delay Test Condition |
50pF |
Maximum Low Level Output Current |
32 mA |
Logic Family |
LVC |
Maximum High Level Output Current |
-32mA |
