| Type of Product | Op Amp |
| Dimension | 4.95 X 3.95 X 1.5 mm |
| Height | 1.5 mm |
| Width | 3.95 mm |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Op Amp |
Dimension |
4.95 X 3.95 X 1.5 mm |
Height |
1.5 mm |
Width |
3.95 mm |
Country of Origin |
China |
Output Current |
13 mA |
Pack of |
20 Pcs |
Mounting Type |
Surface Mount |
Maximum Operating Temperature |
+125°C |
Minimum Operating Temperature |
-40°C |
Length |
4.95 mm |
Name of Manufacturer/Packer/Importer |
Diodes Zetex Semiconductors Limited |
Package Type |
SOIC |
Pin Count |
8 |
Minimum Input Voltage |
-0.2 V |
Maximum Input Voltage |
0.2 V |
Power Supply Type |
Dual |
Typical Dual Supply Voltage |
±1.35 → ±8V |
Voltage Gain |
115 dB (Typical) |
Manufacturer Part Number |
TLV272IS-13 |
Slew Rate |
2.2V/µs (Typical) |
Amplifier Type |
CMOS |
Input Voltage Range |
±0.2 V |
Offset Voltage |
7mV |
Input Offset Current |
1000pA |
Typical Gain Bandwidth Product |
1.9MHz |
Rail to Rail |
Rail to Rail Input/Output |
Typical Input Voltage Noise Density |
35nV/√Hz |
