DiodesZetex NPN Darlington Transistor 1 A 160 V HFE:5000 3-Pin E-Line, ZTX601B (Pack of 4000 Pcs)

Name: DiodesZetex NPN Darlington Transistor 1 A 160 V HFE:5000 3-Pin E-Line, ZTX601B (Pack of 4000 Pcs)
Brand: DiodesZetex
SKU: IND.IND.833791972
Price: 318599 INR
Availability: InStock

Visit the DiodesZetex Store

EMI starts at ₹28307/month. No Cost EMI available.

Available offers

Flat ₹200 off on Order above ₹7,000 | Valid for NEW Business Users

View

Flat ₹100 off on Order above ₹5000 | Valid for NEW Business Users

View

Flat ₹500 off on Order above ₹15000 | Valid for NEW Business Users

View

Flat ₹400 off on Order above ₹10,000 | Valid for REPEAT Business User

View

Features

Type of Product	NPN Darlington Transistor
Dimension	4.77 x 2.41 x 4.01 mm
Height	4.01 mm
Width	2.41 mm

More DiodesZetex Industrial Automation Accessories products More Industrial Automation Accessories products

Warranty as per brand

100% Original Products

Secure payments

100% Buyer protection

Top Brands

specifications

Type of Product	NPN Darlington Transistor
Dimension	4.77 x 2.41 x 4.01 mm
Height	4.01 mm
Width	2.41 mm
Country of Origin	China
Pack of	4000 Pcs
Mounting Type	Through Hole
Maximum Operating Temperature	+200°C
Minimum Operating Temperature	-55°C
Length	4.77 mm
Name of Manufacturer/Packer/Importer	Diodes Zetex Semiconductors Limited
Package Type	E-Line
Pin Count	3
Manufacturer Part Number	ZTX601B
DC Current Gain	5000 (Min.)
Number of Elements Per Chip	1
transistor Type	NPN
Maximum Collector Emitter Voltage	160 V
Transistor Configuration	Single
Maximum Emitter Base Voltage	10 V
Maximum Collector Base Voltage	180 V
Maximum Base Emitter Saturation Voltage	1.9 V
Maximum Collector Emitter Saturation Voltage	1.2 V
Maximum Continuous Collector Current	1 A
Maximum Collector Cut-off Current	0.00001 mA
