| Type of Product | DMP P-Channel MOSFET |
| Height | 0.78 mm |
| Width | 3.35 mm |
| Country of Origin | United Kingdom |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
DMP P-Channel MOSFET |
Height |
0.78 mm |
Width |
3.35 mm |
Country of Origin |
United Kingdom |
Pack of |
3000 Pcs |
Mounting Type |
Surface Mount |
Maximum Operating Temperature |
+150°C |
Minimum Operating Temperature |
-55°C |
Length |
3.35 mm |
Series |
DMP |
Name of Manufacturer/Packer/Importer |
Diodes Zetex Semiconductors Limited |
Package Type |
PowerDI3333-8 |
Pin Count |
8 |
Manufacturer Part Number |
DMP3007SFG-13 |
Continuous Drain Current |
70 A (Max.) |
Drain Source Voltage |
30 V (Max.) |
Channel Type |
P |
Number of Elements Per Chip |
1 |
Channel Mode |
Enhancement |
Maximum Gate Threshold Voltage |
3 V |
Maximum Drain Source Resistance |
13 mΩ |
Maximum Gate Source Voltage |
±25 V |
Minimum Gate Threshold Voltage |
1V |
Typical Gate Charge @ Vgs |
64.2 nC @ 10 V |
Forward Diode Voltage |
1.2V |
Maximum Power Dissipation |
2.8 W |
Transistor Configuration |
Single |
