| Type of Product | Hex Schmitt Trigger Inverter IC |
| Dimension | 8.74 x 3.99 x 1.48 mm |
| Height | 1.48 mm |
| Width | 3.99 mm |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Hex Schmitt Trigger Inverter IC |
Dimension |
8.74 x 3.99 x 1.48 mm |
Height |
1.48 mm |
Width |
3.99 mm |
Country of Origin |
China |
Pack of |
25 Pcs |
Mounting Type |
Surface Mount |
Input Type |
Schmitt Trigger |
Maximum Operating Temperature |
+125°C |
Minimum Operating Temperature |
-40°C |
Length |
8.74 mm |
Name of Manufacturer/Packer/Importer |
Diodes Zetex Semiconductors Limited |
Package Type |
SOIC |
Pin Count |
14 |
Output Type |
Push-Pull |
Minimum Operating Supply Voltage |
4.5 V |
Maximum Operating Supply Voltage |
5.5 V |
Manufacturer Part Number |
74HCT14S14-13 |
Logic Function |
Inverter |
Number of Elements Per Chip |
6 |
Schmitt Trigger Input |
Yes |
Maximum Propagation Delay Time at Maximum CL |
51 ns @ 50 pF |
Propagation Delay Test Condition |
50pF |
Maximum Low Level Output Current |
4 mA |
Logic Family |
HCT |
Maximum High Level Output Current |
-4mA |
