| Type of Product | Bi-Directional TVS Diode |
| Dimension | 4.57 x 3.94 x 2.42 mm |
| Height | 2.42 mm |
| Width | 3.94 mm |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Bi-Directional TVS Diode |
Dimension |
4.57 x 3.94 x 2.42 mm |
Height |
2.42 mm |
Width |
3.94 mm |
Country of Origin |
United Kingdom |
Pack of |
50 Pcs |
Mounting Type |
Surface Mount |
Maximum Operating Temperature |
+150°C |
Minimum Operating Temperature |
-55°C |
Length |
4.57 mm |
Name of Manufacturer/Packer/Importer |
Diodes Zetex Semiconductors Limited |
Package Type |
DO-214AA (SMB) |
Pin Count |
2 |
Surge Current Rating |
100A |
Manufacturer Part Number |
SMBJ6.0CA-13-F |
Test Current |
10 mA |
Diode Configuration |
Single |
Number of Elements Per Chip |
1 |
Direction Type |
Bi-Directional |
Minimum Breakdown Voltage |
6.67V |
Maximum Clamping Voltage |
10.3V |
Peak Pulse Power Dissipation |
600W |
Maximum Reverse Leakage Current |
800 µA |
Maximum Reverse Stand-off Voltage |
6V |
Maximum Peak Pulse Current |
58.3A |
