| Type of Product | TRIAC |
| Dimension | 6.73x6.22x2.39 mm |
| Height | 2.39 mm |
| Width | 6.22 mm |
Type of Product |
TRIAC |
Dimension |
6.73x6.22x2.39 mm |
Height |
2.39 mm |
Width |
6.22 mm |
Country of Origin |
Thailand |
Pack of |
20 Pcs |
Mounting Type |
Surface Mount |
Maximum Operating Temperature |
+125°C |
Minimum Operating Temperature |
-40°C |
Length |
6.73 mm |
Name of Manufacturer/Packer/Importer |
Fagor Electronica |
Package Type |
DPAK (TO-252) |
Pin Count |
3 |
Product Code |
1231475 |
Repetitive Peak Off-State Current |
1 mA |
Repetitive Peak Forward Blocking Voltage |
600V |
Repetitive Peak Reverse Voltage |
600V |
Maximum Gate Trigger Current |
10 mA |
Peak On-State Voltage |
1.6V |
Maximum Gate Trigger Voltage |
1.3V |
Maximum Holding Current |
10 mA |
Rated Average On-State Current |
8A |
Manufacturer Part Number |
FT0808MD TR |
