| Type of Product | TRIAC |
| Dimension | 10.28x4.82x15.75 mm |
| Height | 15.75 mm |
| Width | 4.82 mm |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
TRIAC |
Dimension |
10.28x4.82x15.75 mm |
Height |
15.75 mm |
Width |
4.82 mm |
Country of Origin |
United Kingdom |
Pack of |
10 Pcs |
Mounting Type |
Through Hole |
Maximum Operating Temperature |
+110°C |
Minimum Operating Temperature |
-40°C |
Length |
10.28 mm |
Name of Manufacturer/Packer/Importer |
Littelfuse |
Package Type |
TO-220AB |
Pin Count |
3 |
Product Code |
8062438 |
Repetitive Peak Off-State Current |
2 mA |
Repetitive Peak Forward Blocking Voltage |
800V |
Surge Current Rating |
70A |
Repetitive Peak Reverse Voltage |
800V |
Maximum Gate Trigger Current |
5 mA |
Peak On-State Voltage |
1.85V |
Maximum Gate Trigger Voltage |
1.5V |
Maximum Holding Current |
10 mA |
Rated Average On-State Current |
8A |
Manufacturer Part Number |
MAC8SNG |
