| Model No | ULR-1000 |
| Type of Product | Digicolor |
| Protection Class | IP50 |
| Country of Origin | Japan |
Model No |
ULR-1000 |
Type of Product |
Digicolor |
Protection Class |
IP50 |
Country of Origin |
Japan |
Mass (g) |
About 220 |
Monotaro ID |
38639727 |
Display |
Count / 7-segment LED (red) |
Shank Diameter (Φmm) |
(Mounting) 20 |
Vibration Resistance |
30 minutes at 49m / s ² (5G) |
Import Country |
Direct Import from Japan |
Storage Temperature Range |
-20 to 80℃ |
Operating Temperature Range |
0 to 45℃ |
Name of Manufacturer/Packer/Importer |
MUTOH HOLDINGS CO., LTD. |
Character Height (mm) |
8 |
Position |
Decimal point / arbitrary setting possible (1 / 0.1 / 0.01 / 0.001 / 0.0001) |
Current Consumption (mA) |
150 or less |
Input Power |
DC 10 to 26.5 V |
Maximum Count |
(Measurement length) ± 99999, (Angle) ± 360.00 |
Count Mode |
(Measurement) 10.2 binary, (Angle) 10.5-1.1 minute, 0.01 degree |
Reset |
MANUAL RESET |
Allowable Rotation Speed (min-1 [rpm]) |
700 |
Digit Number of Display |
±5 |
Maximum value measured |
(Lead) 0.01 / 40mm, 0.1 / 400mm |
Power Cable |
With 2m crimp terminal |
Memory Function |
Non-volatile memory backup |
Shock Resistance (m/s²) |
(Durability) 294 (30G) |
