| Model No | CLR-600B |
| Type of Product | Digicolor |
| Protection Class | IP50 |
| Type | Digital color length measuring unit |
Model No |
CLR-600B |
Type of Product |
Digicolor |
Protection Class |
IP50 |
Type |
Digital color length measuring unit |
Country of Origin |
Japan |
Mass (g) |
About 900 |
Monotaro ID |
38639684 |
Display |
Count / 7-segment LED (red) |
Shank Diameter (Φmm) |
(Mounting) 35 |
Vibration Resistance |
30 minutes at 49m / s ² (5G) |
Import Country |
Direct Import from Japan |
Storage Temperature Range |
-20 to 80℃ |
Operating Temperature Range |
0 to 45℃ |
Name of Manufacturer/Packer/Importer |
MUTOH HOLDINGS CO., LTD. |
Character Height (mm) |
10 |
Power Consumption (W) |
2.2000000000000002 |
Input Power |
AC 100 V ±10%(50/60 Hz) |
Maximum Count |
(Measurement length) ± 99999, (Angle) ± 360.00 |
Reset |
MANUAL RESET |
Specifications |
Reverse view |
Allowable Rotation Speed (min-1 [rpm]) |
(Maximum) 700 |
Digit Number of Display |
±5 |
Maximum value measured |
(Lead) 0.01 / 24mm, 0.1 / 240mm |
Power Cable |
With 2m plug |
Memory Function |
Non-volatile memory backup |
Shock Resistance (m/s²) |
(Durability) 294 (30G) |
