| Model No | XG8V-0744 |
| Type of Product | Original Plug 1 Row Type |
| Standard | RoHS compliant, UL standard (File No. E103202) |
| No. of Pole | 7 Pole |
Model No |
XG8V-0744 |
Type of Product |
Original Plug 1 Row Type |
Standard |
RoHS compliant, UL standard (File No. E103202) |
No. of Pole |
7 Pole |
Country of Origin |
JAPAN |
Monotaro ID |
46600976 |
Dimension B (Φmm) |
15.24 |
Terminal Shape |
1 row type, L type terminal |
Shape |
Original plug 1 row type |
Processing (Contact Terminal Pressure Connection Part) |
Nickel base tin plating (2.0 μm) |
Processing (Contact Connection Part) |
Nickel base gold plating (0.15 μm) |
Material (Contact Terminal Pressure Connection Part) |
Brass |
Material (Foot Plate) |
Glass-filled PBT resin (UL94V-0) / Black |
Material (Contact Connection Part) |
Brass |
Rated Voltage (V) |
AC 300 |
Withstand Voltage |
AC 650 V, 1 min (leakage current 1 mA or less) |
Import Country |
Direct Import from Japan |
Part No |
64-3396-31 |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Operation Ambient Temperature (°C) |
-55 to +105 (no freezing in the bass) |
Insulation Resistance (MOhm) |
10³ Or More (At 500 V DC) |
Contact Resistance (ohm) |
20 mΩ or less (20 mV mΩ or less, 100 mA or less) Value when mated with XG5M-N |
Dimension A (Φmm) |
17.8 |
