| Model No | F-700-A |
| Type of Product | Fuse Holder Horizontal Connection Type |
| Material | P.B.T. (UL94V-0) |
| Suitable For | FG-20, FG-30, etc. |
Model No |
F-700-A |
Type of Product |
Fuse Holder Horizontal Connection Type |
Material |
P.B.T. (UL94V-0) |
Suitable For |
FG-20, FG-30, etc. |
Type |
Fuse holder |
Country of Origin |
Japan |
Monotaro ID |
45536714 |
Pack of |
1 Pcs |
Withstand voltage (V / min) |
AC2000 |
Insulation Resistance |
DC500V, 100MΩ or more |
Rated Current (A) |
10 |
RoHS Directive |
Correspondence |
Rated Voltage (V) |
250 |
Tightening Torque (Nm) |
1 (when using M4 screw, flat washer), 1.2 (terminal screw) |
Import Country |
Direct Import from Japan |
Type of Sign |
DIN rail mounting |
Terminal |
Screw terminal, M4 Sems screw |
Name of Manufacturer/Packer/Importer |
Sato Parts Co., Ltd. |
Body Color |
White |
suitable crimping terminal |
Screw tightening terminal (M4 x 8 sems screw) |
Insulator Material |
P.B.T.(UL94V-0) |
Specifications |
DIN rail mountable |
Insulation_Resistance (MΩ) |
DC500V, 100 mΩ or More |
Applicable fuse tube size (mm) |
Φ6.4x30, Φ6.35x30, Φ6.35x31.8 |
Standard to Conform |
UL standard / C-UL standard |
