| Type of Product | PCB Mount Reed Relay |
| Dimension | 60 x 15.8 x 24.8mm |
| Depth | 15.8mm |
| Height | 24.8mm |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
PCB Mount Reed Relay |
Dimension |
60 x 15.8 x 24.8mm |
Depth |
15.8mm |
Height |
24.8mm |
Country of Origin |
United Kingdom |
Mounting Type |
PCB Mount |
Terminal Type |
Quick Connect |
Contact Configuration |
SP-NC |
Coil Voltage |
12V dc |
Contact Material |
Tungsten |
Contact Resistance |
250 mΩ |
Maximum Operating Temperature |
+70°C |
Minimum Operating Temperature |
-20°C |
Length |
60mm |
Operating Temperature Range |
-20 → +70°C |
Coil Resistance |
240Ω |
Name of Manufacturer/Packer/Importer |
SENSATA / CYNERGY3 |
Manufacturer Part Number |
DBT71210S |
Maximum Switching Voltage (AC) |
7000V |
Maximum Switching Current DC |
2 A |
Operating Time Including Bounce |
2ms |
Maximum Switching Voltage DC |
7000V dc |
Operating Cycle |
1000000 (Electrical) cycles |
Special Features |
Low Contact Resistance, High Power Switching |
Electrical Life |
1000000 (Electrical) Cycles |
Maximum Switching Current AC |
2 A |
Isolation Coil To Contact |
17kV ac/dc |
Maximum Switching Power DC |
50 W |
Maximum Switching Current (AC) |
2 A |
Maximum Switching Current (DC) |
2 A |
Maximum Switching Voltage (DC) |
7000V dc |
