| Type of Product | Piezo Buzzer |
| Dimension | 24x24x15.5 mm |
| Depth | 24 mm |
| Diameter | 24 mm |
Type of Product |
Piezo Buzzer |
Dimension |
24x24x15.5 mm |
Depth |
24 mm |
Diameter |
24 mm |
Height |
15.5 mm |
Country of Origin |
United Kingdom |
Mounting Type |
Through Hole |
Maximum Operating Temperature |
+70°C |
Minimum Operating Temperature |
-20°C |
Length |
24 mm |
Name of Manufacturer/Packer/Importer |
Sonitron |
Product Code |
1784024 |
Minimum Supply Voltage |
1.5 V DC |
Maximum Supply Voltage |
15 V DC |
Manufacturer Part Number |
SMA-24L-P17.5 |
Minimum Frequency |
2550Hz |
Maximum Frequency |
3.45 kHz |
Sound Level |
98dB |
Supply Current |
6.7 mA |
Drive Type |
Internal |
Tone Type |
Continuous |
