| Model No | ACST410-8BTR |
| Type of Product | TRIAC |
| Dimension | 6.73x6.22x2.4 mm |
| Height | 2.4 mm |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Model No |
ACST410-8BTR |
Type of Product |
TRIAC |
Dimension |
6.73x6.22x2.4 mm |
Height |
2.4 mm |
Width |
6.22 mm |
Country of Origin |
USA |
Pack of |
10 Pcs |
Mounting Type |
Surface Mount |
Maximum Operating Temperature |
+125°C |
Minimum Operating Temperature |
-40°C |
Length |
6.73 mm |
Name of Manufacturer/Packer/Importer |
RS Components & Controls (I) Ltd |
Package Type |
DPAK (TO-252) |
Pin Count |
3 |
Repetitive Peak Off-State Current |
0.5 µA |
Repetitive Peak Forward Blocking Voltage |
800 V |
Surge Current Rating |
32 A |
Repetitive Peak Reverse Voltage |
800 V |
Maximum Gate Trigger Current |
10 µA |
Peak On-State Voltage |
1.7 V |
Maximum Gate Trigger Voltage |
1 V |
Maximum Holding Current |
20 mA |
Rated Average On-State Current |
4 A |
