| Model No | Z0103MN 5AA4 |
| Type of Product | TRIAC |
| Dimension | 6.7x3.7x1.8 mm |
| Height | 1.8 mm |
Model No |
Z0103MN 5AA4 |
Type of Product |
TRIAC |
Dimension |
6.7x3.7x1.8 mm |
Height |
1.8 mm |
Width |
3.7 mm |
Country of Origin |
USA |
Pack of |
1000 Pcs |
Mounting Type |
Surface Mount |
Maximum Operating Temperature |
+125°C |
Minimum Operating Temperature |
-40°C |
Length |
6.7 mm |
Name of Manufacturer/Packer/Importer |
RS Components & Controls (I) Ltd |
Package Type |
SOT-223 |
Pin Count |
3+Tab |
Surge Current Rating |
8.5 A |
Repetitive Peak Reverse Voltage |
600 V |
Maximum Gate Trigger Current |
5 µA |
Peak On-State Voltage |
1.6 V |
Maximum Gate Trigger Voltage |
1.3 V |
Maximum Holding Current |
7 mA |
Rated Average On-State Current |
1 A |
