| Model No | BTA40-600B |
| Type of Product | TRIAC |
| Dimension | 40x27x14 mm |
| Height | 14 mm |
Model No |
BTA40-600B |
Type of Product |
TRIAC |
Dimension |
40x27x14 mm |
Height |
14 mm |
Width |
27 mm |
Country of Origin |
USA |
Pack of |
25 Pcs |
Mounting Type |
Panel Mount |
Maximum Operating Temperature |
+125°C |
Minimum Operating Temperature |
-40°C |
Length |
40 mm |
Name of Manufacturer/Packer/Importer |
RS Components & Controls (I) Ltd |
Package Type |
RD-91 |
Pin Count |
3 |
Repetitive Peak Off-State Current |
0.005 µA |
Repetitive Peak Forward Blocking Voltage |
600 V |
Surge Current Rating |
420 A |
Repetitive Peak Reverse Voltage |
600 V |
Maximum Gate Trigger Current |
100 µA |
Peak On-State Voltage |
1.55 V |
Maximum Gate Trigger Voltage |
1.3 V |
Maximum Holding Current |
80 mA |
Rated Average On-State Current |
40 A |
