| Size | 96x96x54 mm (HxWxD) |
| Display | 4-Digit 7-Segment Red LED Display |
| Operating Temperature | 0°C-55°C |
| Frequency | 50-60 Hz |
Size |
96x96x54 mm (HxWxD) |
Display |
4-Digit 7-Segment Red LED Display |
Operating Temperature |
0°C-55°C |
Frequency |
50-60 Hz |
Type of Product |
Process Indicator |
Range |
-999 to 9999 (For all I/P) |
Resolution |
Decimal Point Selectable: 0.1, 0.01, 0.001, 0001 |
Model No |
PIC-1102 |
Display Size |
1.42 cm (0.56 inch) |
Country of Origin |
India |
Panel Cutout |
92x92 mm (HxW) |
Relative Humidity |
Upto 95% RH Non-Condensing |
Name of Manufacturer/Packer/Importer |
Dhruv Enterprise |
Supply Voltage |
100-270 V AC |
Indication Accuracy |
±1% FSD ± 1 Digit |
Input Current |
0 to 20 mA DC, 4 to 20 mA DC |
Relay Type |
1 C/O (NO-C-NC) |
Relay Rating |
5 A, 230 V AC |
Input Voltage |
0 to 10 V DC |
Power Consumption (VA) |
4 VA @230 V AC (Max) |
