| Type of Product | Φ30 TWND Series |
| Model No | ALFD24611DNR |
| Country of Origin | Japan |
| Name of Manufacturer/Packer/Importer | IDEC Corporation |
Type of Product |
Φ30 TWND Series |
Model No |
ALFD24611DNR |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
IDEC Corporation |
Contact Configuration |
1A1B |
Protection Class |
IP65 |
Contact Resistance |
50 mΩ or Less (Initial Value) |
Storage Temperature |
-40 To 80°C (No Icing) |
Contact Material |
Silver |
Monotaro ID |
48042979 |
Terminal Shape |
M3.5 Screw Terminal |
Import Country |
Direct Import from Japan |
Operation Type |
Momentary |
Mounting Hole Diameter (Φmm) |
30.5 mm (0 - 0.5) |
Operation Ambient Temperature (°C) |
-25-50°C (No Icing) |
Insulation_Resistance (MΩ) |
100 MΩ or more (DC500V mega) |
Rated Carrying Current (A) |
10A |
Rated Insulation Voltage (V) |
600 V |
Type of Illumination |
LED |
Vibration Resistance (Malfunction) |
5-55 Hz, Single Amplitude 0.5 mm |
Name |
Push Button Switch (Zinc Die-Cast) |
Vibration Resistance (Destruction) |
30 Hz, 1.5 mm Single Amplitude |
Lamp Voltage (V) |
AC400/440 V |
