| Type of Product | Flash Silhouette CW Series Illuminated Pushbutton Switch |
| Model No | CW1L-A1E22QHA |
| Material | Polyamide Resin (Bezel Material) |
| Country of Origin | Japan |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Flash Silhouette CW Series Illuminated Pushbutton Switch |
Model No |
CW1L-A1E22QHA |
Material |
Polyamide Resin (Bezel Material) |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
IDEC Corporation |
Color |
Amber |
Contact Configuration |
2A-2B |
Protection Class |
Terminal part: IP20 (IEC60529) |
Contact Resistance |
50 mΩ or Less (Initial Value) |
Contact Material |
Silver |
Monotaro ID |
29181207 |
Terminal Shape |
Screw Terminal (M3.5 Dual Use Screw) |
Import Country |
Direct Import from Japan |
Operation Type |
Alternate Type |
Shape |
Round Flat |
Insulation_Resistance (MΩ) |
100 MΩ or more (with DC500V mega) |
Rated Carrying Current (A) |
10A |
Rated Insulation Voltage (V) |
300 V |
Vibration Resistance (Malfunction) |
5-55 Hz, Single Amplitude 0.5 mm |
Vibration Resistance (Destruction) |
30 Hz, 1.5 mm Single Amplitude |
Bezel Color |
Black |
Rated Operating Voltage (V) |
AC100/120 |
Impact Resistance (Durability) (m/s²) |
1000 |
Electric Shock Protection Class |
ClassⅡ(IEC61140) |
Impact Resistance (Malfunction) (m/s²) |
100 |
Rated Impulse Withstand Voltage (kV) |
2.5(IEC60664-1/IEC60947-5-1) |
