| Type of Product | CS Series cam switch |
| Model No | UCSQO-129-S2B-C1014 |
| Country of Origin | Japan |
| Name of Manufacturer/Packer/Importer | IDEC Corporation |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
CS Series cam switch |
Model No |
UCSQO-129-S2B-C1014 |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
IDEC Corporation |
Contact Configuration |
Double Cut-Off Slow Action With 2 Contacts Per Stage |
Suitable For |
ACSNO type, UCSQO type, UCSQM type |
Protection Class |
IP40(IEC 60529) |
Storage Temperature |
-40 To 80°C (No Icing) |
Contact Material |
Silver Contacts |
Handle Color |
Black |
Monotaro ID |
47994146 |
Import Country |
Direct Import from Japan |
Operation Ambient Temperature (°C) |
-20 To 50°C (But Not Freezing) |
Insulation_Resistance (MΩ) |
100 MΩ (DC500V mega) |
Rated Carrying Current (A) |
10A |
Rated Insulation Voltage (V) |
600 V |
Operating Ambient Humidity (% RH) |
45 To 85 (No Condensation) |
Compatible Handle |
S2 |
Notch Angle |
90° |
Operation method |
Each Position Stop Type |
Number of Notches |
2 |
No. of Tiers |
1 Stage (Contact Block) |
Withstand voltage (V / min) |
Between live parts and non-live parts: AC2500 |
Circuits |
Number: C1014 |
